Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports

Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports

    • Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports
    • Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports
    • Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports
    • Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports
  • Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports

    Product Details:

    Place of Origin: China
    Brand Name: BIO
    Model Number: 5000L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Packaging Details: Carton (41*32*41cm ) 6kgs
    Delivery Time: 7 working - days since getting full payment
    Payment Terms: Credit card, Paypal, T/T
    Supply Ability: 100 units / month
    Contact Now
    Detailed Product Description
    Scanning Mode: B, 2B, 4B, B+M, CFM, PDI, DPDI, PW, B+PW(Duplex) B+CFM/PDI/DPDI+PW(Triplex) Multi - Frequency: 2~12MHz
    USB Ports: 2 Monitor: 12.1-inch LED Monitor
    Probe Ports: 2 Display Depth: 30cm
    Weight: 5.5 Kg (with Battery) Dimensions: 29.8*31.8*13.8cm

    Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports



    The portable Color Doppler system 5000L with superior image, high performance and low cost is your right choice .

    BIO makes efforts to let each person can get high- quality medical services.

    5000L is the one that can meet your various requirement with an affordable price.

    User-friendly interface can make doctors work more efficiently.

    BIO 5000L is based on the Fifth technology platform, which is a latest portable color Doppler ultrasound system.

    It is one not only with advanced image processing technology but also practical clinical solutions.



    Advantage

    1 3D imaging for optional
    2 Intuitive operation with Auto one-key image optimization
    3 Instant images and reports transfer to PC
    4 Streamlined work-flow, clean and convenient report system
    5 Build-in 128G SSD,data storage more steadily
    6 Rechargeable lithium-ion battery:2 hours continuous work
    7 Application:Abdomen,Gynecology,Obstetrics,Urology,Blood vessel,MSK,Small parts
    8 Slim and elegant appearance design,less than 6 kg net weight
    9 Auto Trace Calculation PW
    10 Ultra-wide-band beam former
    11 Intelligent imaging optimization technology
    12 E-Crystal Unique Speaker Reduction Technology
    13 AQ-Sonic Unique Noise Reduction Technology
    14 Real-time triplex display B/Color Doppler/Pulse Wave Doppler



    Specifications

    Net Weight 5.5 kg (with battery)
    Dimensions 29.8*31.8*13.8cm
    Display 12.1-inch LED monitor
    Display Language English
    Power

    System operates via AC power

    Large capacity Li-battery

    -11.1V, 8000MAH;

    -up to 1000 times charge-discharge,2 hours fully charged

    -Removable

    -2.5 hours regular use

    -Auto switch to battery power in case of suddenly power off

    Ports

    - USB: 2 USB interface can be connected directly to the electronic printing device to print report and to copy data by mobile storage device

    - HDMI:Can be converted to VGA output interface,director connection to a high-resolution display and other display and other display devices,more convenient for patient to show an ultrasound image.

    - LAN: It can be used directly connected the data cable and transfer data to the internet.

    Display mode and

    Broadband, multi-frequency imaging:

    B, 2B, 4B, B+M, CFM, PDI, DPDI, PW, B+PW(Duplex)

    B+CFM/PDI/DPDI+PW(Triplex)

    Imaging processing

    - AQ sonic:Reduce random noise

    - E Crystal:Adaptive speckle suppression improves contrast resolution

    - Multi-frequency probes for LD imaging modes

    - Ultra-wideband beamformer

    - intelligent imaging optimization technology

    - Image Zooming

    - Near and far Gain adjustment.

    - With dual and duplex imaging.

    - 2D, Color Doppler and PW displaying on one screen in real time

    User Interface

    - Alphanumeric QWERTY keyboard with Backlight

    - 8 Segment TGC

    - Focus: 4-point adjustment

    - Automatic gain control

    -With Doppler angle and angle correction

    Intelligent work flow/storage/review

    - Images saved into hard disk(64G SSD) or transferred to PC via USB

    - 2 USB ports

    -Image formats: BMP, JPG, DCM, FRM,CIN

    - B mode: 1024frames

    - M mode: 12.4 s

    -Frame rate: not less than 50fps

    -Display depth: minimum 30cm

    -High-Resolution:1024 *768

    -Grayscale: 256

    -Body markers: more than 100 Dynamic range, ≤165dB

    Application

    - OB/GYN reporting.

    - Small part analysis

    - Cardiac analysis with intimate medial thickness measurement

    - Velocity Colour to detect colour flow with PW Abdominal, Obstetrical, Gynecological, Cardiac, Small parts, Urological, Vascular, Orthopedics, MSK



    Video








    Standard Configuration

    1. 12.1-inch LED monitor
    2. Two transducer connector
    3. Control Panel
    4. 2 USB ports
    5. HDMI
    6. LAN
    7. Handle
    8. Indicators: Power/Battery/Standby



    Options

    1. 3D function
    2. Sony UP-897MD Printer
    3. One more Battery
    4. Gel
    5. printer paper
    6.

    Trolley



    Optional probe

    5ACR60 Convex probe R=60mm 2-5MHz
    5AL40 Linear probe L=40mm 5-10MHz
    5AL25 Linear probe L=25mm 5-12MHz
    5AMCR20 Micro-Convex probe R=20mm 2-4MHz
    5AMCR11 Micro-Convex probe R=11mm 5-8MHz
    5AMCVR Transvaginal probe R=10mm 5-8MHz



    Images

    Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports

    Color Doppler Ultrasound System Portable Ultrasound Scanner With 12.1 Inch LED Monitor And 2 Probe Ports
