B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe

B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe
B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe

Large Image :  B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe

Product Details:
Place of Origin: China
Brand Name: BIO
Model Number: 5000A
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Packaging Details: Carton (41×21×31cm) 6kgs
Delivery Time: 7 working - days since getting full payment
Payment Terms: Credit card, Paypal, T/T
Supply Ability: 100 units / month

B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe

Description
Display: 15 Inch LCD Resolution: 1024*768 Pixels
Color Depth: 24 Bit Grey Levels: 256
Scanning Depth: 2~30cm USB Ports: 2
Transducer Ports: 2 Hard Disc: 64GB (SSD)
High Light:

portable ultrasound equipment

,

portable ultrasound device

B Ultrasound Scanner Portable Ultrasound Scanner with Built-in 4D Module with Optional 4D Volume Probe



Powerful function & Configuration

1 • Large screen display
2 • Built-in lithium battery
3 • Small size, light weight, easy to carry, N.W. ≤ 5kg
4 • Equipped with a wide range of probes for abdominal, obstetric, vascular, cardiac, small organ, urinary applications
5 • Built-in 4D module with optional 4D volume probe
6 • A variety of digital peripheral interfaces, provides a variety of image output methods
7 • PC platform, easy to operate, meet various software upgrades



Rich clinical application function

1 • B+CF (Dual Images) • B+CF/PDI/DPDI+PW (Triplex)
2 • Convex extended imaging technology
3 • Linear array deflection/Trapezoidal imaging technology
4 • Spatial compound Imaging technology
5 • Panoramic imaging technology (optional)
6 • 3D/4D imaging technology (optional)
7 • Speckle noise removal technology
8 • Pulse inversion tissue harmonic imaging technology (iTHI)


Digital Specification

Size (Diagonal) 15"LED display
Contrast Ratio 800:01:00
Resolution 1024*768 pixels
Brightness 230 cd/m2
Color Depth 24bit
Rotate Angle ± 18°
Grey Levels 256
Scanning depth 2-30cm
Transducer Ports 2
USB Ports 2
3D/4D module 3D/4D probe optional
Hard Disc 64GB (SSD), 120G/200GB SSD (Optional)
Printing Area Image, report, Image+report
Ethernet Port 2(100Mb/1000Mb)
External Display VGA, HDMI,etc..
Printer(Optional) USB Printer, Digital Laser Printer, Digital B/W Thermal Printer
Pan/Zoom Real-Time Image Zoom, Zoom Range: 100%~400%, Up/Down/Left/Right Inversion
Scanning Method electronic linear, electronic convex, electronic micro-convex,
electronic phased array, 4D probe



General Performance
Digital Broadband 12288 channels
Beam-former Re-programmable
Transmit Voltage Adjustable (15 steps)
Beam-former Frequency Range 1~40 MHz
Color Doppler
PRF variable 0.6-20kHz
Wall filter settings ≥ 5 steps
Angle steering for linear transducers ±5°, ±10°, ±15°
Real-time spatial filter ≥ 4 values
CFM palette ≥10 maps
PDI palette ≥10 maps
Doppler frequency selection ≥ 4 values
B/Color priority control / Color threshold control / CFM baseline control
color frame averaging / Transparent Color Mapping (TCM)
Pulsed Wave Doppler
PRF variable 0.6-20 kHz
Wall filter settings ≥ 10 steps
Angle steering for linear transducers ±5°, ±10°, ±15°
Stereo sound volume control
PWD palette ≥10 maps
Doppler frequency selection ≥ 4 values
Real-time trace line with automatic calculation of spectrum parameters
