Product Details:
|
| Measuring Function: | Distance, Circumference/area (method Of Ellipse, Method Of Loci), Volume, Heart Rate, Gestational Weeks (BPD, GS, CRL, FL, AC), Expected Date Of Confinement And Fetus Weight, Etc | Display: | 12 Inch LED Screen(1024*768) |
|---|---|---|---|
| System: | Window 10 System(PC) | Display Mode: | B,B+B,4B,,B+M |
| USB Port: | 2 | Memory Disk: | 64GB SSD |
| B Mode: | 1024 Frames | M Mode: | 12.5s |
| Highlight: | portable ultrasound machine,portable ultrasound device |
||
Advantage
| 1. | 12 inch LED screen |
| 2. | One-key optimization setting |
| 3. |
Advanced image technology: E-Crystal,AQ-Sonic,make the clinical images smooth and clear |
| 4. |
E-focus: the number of focus,the position of focus and focus space could be adjusted |
| 5. | windows 10 system:for running stable and updating software easily and fast |
| 6. |
Large capacity of cine loop and image permanent storage |
| 7. |
Build-in battery:make sure 2 hours operation continuously to prevent the loss of information |
| 8. | measurement software package:used for abdomen,GYN,OB,Small parts,Vessel,Urology,MSK and Cardiac |
| 9. |
Speckle noise rejection technology:Select different options on depending on the different characteristic of different tissues , speckle and noise reduction can improve the imaging quality. |
Standard configuration Optional configuration
| 12 inch LED monitor | Carrying case |
| 2 transducer connectors | PC Printer |
| 2 USB ports | Puncture guide |
| 1 LAN port,1 Video output,1 VGA output | Trolley |
Specification
| Display | 12 inch LED screen(1024*768) |
| System | Window 10 system(PC) |
| Display mode | B,B+B,4B,,B+M |
| Image processing | AQ Sonic&E Crystal |
| Dynamic | |
| Frame Average | |
| Image enhancement | |
| Trapezoid Image | |
| Compound image | |
| One-key image optimization | |
| User interface | Alphanumeric QWERTY keyboard |
| Backlight Silicon system | |
| Intelligent work flow | One key to change probe,save images,report system |
| Software package of obstetric,Gynecology,Organ Urinary,Cardiology,etc | |
| Storage | Hard disk or flash disk storage |
| 2 USB ports | |
| Memory disk:64GB SSD | |
| Review | Single-frame image formats:BMP |
| Multi-frame image formats:AVI | |
| Cine memory capacity(Max) | B Mode:1024 frames |
| M Mode:12.5s | |
| Net weight | 5.3kg |
| Package size | 40*38*33cm |
