Name: Portable Ultrasound Unit Portable Ultrasound Scanner 4 Types of Probes Available with Frequency 2~15MHz
Brand: BIO
SKU: 3000P

Home Products Portable Ultrasound Scanner

Portable Ultrasound Unit Portable Ultrasound Scanner 4 Types of Probes Available with Frequency 2~15MHz

Product Details:

Place of Origin:	China
Brand Name:	BIO
Model Number:	3000P

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Packaging Details:	1 unit/carton(51.5cm 40cm13.5cm)
Delivery Time:	7 working - days since getting full payment
Payment Terms:	Credit card, Paypal, T/T
Supply Ability:	100 units / month

Contact Now

Detailed Product Description

Display Mode:	B, B+B, B+M	Connection Way:	USB
Operation System:	Window 10	Screen Size:	4 Sizes Optional
Frequency:	2~15MHz	Weight:	1kg
High Light:	portable ultrasound machine , portable ultrasound device

Portable Ultrasound Unit Portable Ultrasound Scanner 4 Types of Probes Available with Frequency 2~15MHz

BIO 3000P is designed for those who wants convenience and efficiency in the entire ultrasound exam.

It enables a quick look inside your patients, When you meet patients at the point-of-care, you can make a faster diagnosis

and deliver care whenever needed.

Superior performance with a compact body, you deserve a daily visible assistant.

Application

1.	Anesthesis / Pain Management (Nerve, puncture, injection guided, interventional therapy)
2.	Line Placement (CVC, PICC)
3.	Abdominal / Urology (Abdominal aorta, Urinary bladder, Gall bladder, Kidney / Ureter, Liver, Spleen)
4.	Thyroid, Carotid
5.	Pericardial effusion, Chest fluid, Breast, Lung
6.	Vascular access (Artery, Vein, Deep vein, catheterization, AVF puncture, PTA guided)
7.	Fetal / OB (Fetal position, Placenta, Fetal heartbeat, Uterus, Amniotic fluid)
8.	Musculoskeletal

Advantage

1.	Superior Image Quality	Incredible image quality helps you make fast and precise decision
2.	Easy to carry	Zero footprint, light and compact, easily taken to anywhere in your pocket.
3.	Competitive price	Every clinical doctor can afford it and deserve it.
4.	Simple printing and sharing	Print your images directly and share images, video with colleague from your handheld ultrasound via email or shared network.
5.	Wide application	Primary care, Emergncy, Anesthesia, Pain Management, OB /GYN, Med School, Clinical research, Interventional , Sportsmedicine, Home care, Global health and so on.
6.	Steady ultrasound signal	USB connection makes the signal transmission more steady and faster. Different lengths of cable can meed different clinical requirements.
7.	Water proof	Waterproof with sealed head and be disinfected.

Optional probes

Model	C60	L40	L25	C15
Name	Curved array transducer	Linear array transducer	Linear array transducer	Curved array transducer
Frequency	2 to 5MHZ	5 to 12MHZ	6 to 15MHZ	4 to 9MHZ
Display mode	B,B+B,B+M	B,B+B,B+M	B,B+B,B+M	B,B+B,B+M
Application	abdominal,gall bladder,OB/GYN, lung etc	Vascular,Thyroid, Nerve,Superficial, Musculoskeletal and Lung	Vascular,Musculoskeletal, Thyroid,Breast,Nerve,S uperficial,interventional	Abdominal, Pediatrics, VET
USB-C transducer with replaceable cable	√	√	√	√

Supported Device

Device Name	Screen Size	Ram	Internal Storage	Battery Capacity	Weight	Operation System
Pad A	8 inch	2GB	32GB SSD	4500mAh	360g	Windows 10
Pad B	10.1 inch	4GB	64GB SSD	6500mAh	680g	Windows 10
Pad C	11.6inch	6GB	64GB SSD	9000mAh	700g	Windows 10
Pad D	8 inch	4GB	32GB SSD	8000mAh	840g	Windows 10

Images

Ultrasound Scan Equipment Portable Ultrasound Scanner Palm Ipad Ultrasound Machine

Video

Portable Ultrasound Unit Portable Ultrasound Scanner 4 Types of Probes Available with Frequency 2~15MHz 3
