Product Details:
|
| Screen Resolution: | 960*480 | Light Source: | Natural White(LED) |
|---|---|---|---|
| Screen: | 3.5 Inch | Power Supply: | Rechargeable Lithium Battery |
| High Light: | digital otoscope,video otoscope |
||
Handheld Throat Endscope Digital Laryngoscope Micro SD Card With 3.5 Inch LCD Screen
Advantages
| 1 | Bigger LED Screen 3.5 inch with 960*480 screen resolution |
| 2 | Never hot lens with 300 thousand pixel |
| 3 | Disposable earmuff |
| 4 | Wi-Fi built-in |
| 5 | examine external ear and middle ear |
| 6 | cerumen, otitis media, ear infections, perforation of tympanic membrane checking |
| 7 | Small & Light to hold, Easy to carry with aluminum box |
| 8 | Otoscope, Rhinoscope, Laryngoscope three lens Optional |
| 9 | Rechargeable Li-On battery to ensure 4 hours continuous working at least |
| 10 | External LCD is optional which can be connected to otoscope to display larger images in real time. |
Product Specification
| Digital Otoscope Specifications | ||
| Handheld Device | Main Machine | |
| Package Size | 30*25*16cm | |
| Net Weight | 260g | |
| Intended use | Digital Otoscope | |
| Using method | Hand-held digital otoscope | |
| Image System | Light source | Nature white LED light |
| Focus range | 20 ~ 60 mm | |
| Camera | CMOS | |
| Resolution | 720 x 480 pixels (VGA) | |
| Focus system | Fixed | |
| Earcap | No.4 (4.0 mm) | |
| Display | Intergrated display | Full color TFT-LCD |
| Live image export | AV out | |
| Storage type | TF card (1GB) | |
| Image mode | Photo | |
| Format | JEPG | |
| Data transmit | USB | |
| Power | Battery | 3.7 V/ 2200mAH Li-ion Battery with safety protection |
| power supply | 100V-240V AC50/60HZ DC IN+5V 1A | |
| Energy save | Yes | |
Available camera lens
| Lens | Digital Otoscope (ear inspection) | Digital Laryngoscope (throat inspection) | Digital Rhinoscope (nasal inspection) |
| Focus range | 10~50 mm | 80~160mm | 10~50 mm |
| Diameter | 5.5mm | 230mm | 5.5mm |
| Length | 70mm | 70mm | 250mm |
| Weight | 31g | 62g | 31g |
Images
Belows are the catalogue and user's manual for digitals cope for reference:
