Product Details:
|
| Frequency: | 2.2/3.6Mhz | Depth: | 90/130/160/190mm |
|---|---|---|---|
| Display Mode: | B, B/M, Color, PW, PDI | Applications: | Cardiac, Abdomen |
| Measurement: | B: Length,Area/Circumference,Angle,Trace,Distance B+M: Heart Rate, Time, LVIDd, LVIDs, SV, EF, Distance B+PW:Velocity, Heart Rate(2), S/D, Depth | Working System: | Apple IOS And Android, Windows |
| Battery: | Built-in 2800mAh Lithium Battery | Battery Last: | 3 Hours Working Time, More Than 5 Hours Standing By |
| High Light: | 116g Wireless Ultrasound Scanner,2.2 MHz Ultrasound Scanner,B Mode Cardiac Ultrasound Scanner |
||
CE Approved 116g Weight Wireless Ultrasound Machine 2.2/3.6MHz B Mode Ultrasound Scanner
Why is B-mode more useful for medical ultrasonography?
In contrast, a more technologically advanced type of diagnostic ultrasound, known as brightness or B-mode scanning, provides a computer-enhanced two-dimensional image of the underlying tissues similar to that obtained via CAT scans.
Advantages
1. Can be connected to IOS / Android / Windows devices by Wifi or Type-C cable.
2. Smaller design, convenient for sterilization in the operating field.
3. Save more time and costs for doctors and patients.
4. Built-in Wifi and lithium battery support wireless charging
Specification
| 1 | Scanning Mode | Electronic phased array |
| 2 | Probe element | 128 |
| 3 | Frequency | 2.2 / 3.6 MHz |
| 4 | Depth | 90 / 130 / 160 / 190mm |
| 5 | Display mode | B, B/M, Color, PW, PDI |
| 6 | Application | Cardiac, Abdomen |
| 7 | Measurement |
B: Length, Area / Circumference, Angle, Trace, Distance, B+M: Heart rate, time, LVIDd, LVIDs, SV, EF, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth |
| 8 | Image frame rate | 24/s |
| 9 | Cineplay | 100/200/500/1000 |
| 10 | Image save | jpg, avi, mp4 and DICOM format |
| 11 | Wifi type | 802.11g/20MHz/5G/450Mbps |
| 12 | Working system | Apple IOS and Andriod, Windows |
| 13 | Language | English, Russian, Italian, Spanish, Chinese, Portuguess (Brazil) |
| 14 | Battery | Built-in 2800mAh Lithium Battery |
| 15 | Power | consumption 4W (probe sun)/1.5W(probe stop) |
| 16 | Battery last | 3 hours (working time) more than 5 hours (stand by time) |
| 17 | Battery charge | by USB cable / wireless charge |
| 18 | Dinemsion | 127*61*21mm |
| 19 | Weight | 116g |
Standard Configuration
| 1 | Wireless ultrasound probe | 1pc |
| 2 | USB A male to Type-C Female adaptor | 1pc |
| 3 | Portable wireless charger | 1pc |
| 4 | USB Cable for charging | 1pc |
| 5 | Operation manual | 1pc |
| 6 | Type-C cable | 1pc |
Optional
| 1 | ipad Torlley | 1pc |
Images
