Product Details:
|
| Mode: | B, B+M, PW, Color Doppler, Power Doppler | Software: | Download Software From APP Store / Google Play |
|---|---|---|---|
| Available System: | Windows, Android, IOS (Tablet, Smart Phone, PC) | Language: | Chinese, English, Russian, Italian, Spainish, Portuguese |
| Connection: | USB Or Wifi Both OK | Function: | GN(gain), D(Depth), ENH(enhancement), DR(dynamic Range), F(frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page Left/right, Up/down |
| Measurement: | Lengh, Area/circumference, Angle, Trace, Distance, GA(CRL,BPD,GS,FL,HC,AC) EFW(BPD,FL), Heart Rate, Time, Distance, Velocity, Heart Rate(2), S/D, Depth | Frequency: | Linear: 7.5/10MHz, Convex: 2.5/5MHz, 3.5/5MHz |
| High Light: | convex handheld ultrasound scanner,dual heads handheld ultrasound scanner,2.5mhz handheld ultrasound scanner |
||
Handheld USB+WIFI Ultrasound Probe with Dual Heads Convex Linear Phased 3 In 1 Color Doppler
3 IN 1 probe is used widely in clinic, hospital ward, emergency room, or operation theater, easy to carry, convenient to operation.
It can be conected to tablet, smart phone, PC etc via WIFI or USB cable, Windows / Android / IOS system are all avaiable.
Download our ultrasound software from APP store / Google Play.
You can scan anybody anytime anywhere conveniently in time.
Specification
| 1 | Mode | B, B+M, PW, Color Doppler, Power Doppler |
| 2 | Frequency | Linear: 7.5/10MHz, Convex: 2.5/5MHz, 3.5/5MHz |
| 3 | Depth | Linear: 20-100mm, Convex:L90-160mm, 90-305mm |
| 4 | Transducer | Dual heads (Convex & Linear) |
| 5 | Connection | USB or Wifi both OK |
| 6 | Software | Download software from APP store / Google Play |
| 7 | Language | Chinese, English, Russian, Italian, Spainish, Portuguese |
| 8 | Function | GN(gain), D(Depth), ENH(enhancement), DR(dynamic range), F(frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right, up/down |
| 9 | Measurement | Lengh, Area/circumference, Angle, Trace, Distance, GA(CRL,BPD,GS,FL,HC,AC) EFW(BPD,FL), Heart rate, Time, Distance, Velocity, Heart Rate(2), S/D, Depth |
| 10 | Battery | 2800mAh Working time >3h, Standby time: >12h |
| 11 | Length | 125mm |
| 12 | Net Weight | 90g |
Standard Configuration
| 1 | Wireless probe | 1pc |
| 2 | USB cable | 1pc |
| 3 | Power Plug | 1pc |
| 4 | Wireless charger | 1pc |
| 5 | Wrist strap | 1pc |
| 6 | Portable aluminium alloy box | 1pc |
| 7 | User's Manual_E format | 1pc |
| 8 | Warranty Card_Eformat | 1pc |
Images
