PDI WiFi Wireless Portable Ultrasound Scanner 128 Element

PDI WiFi Wireless Portable Ultrasound Scanner 128 Element

PDI WiFi Wireless Portable Ultrasound Scanner 128 Element
video
PDI WiFi Wireless Portable Ultrasound Scanner 128 Element
Product Details:
Place of Origin: China
Brand Name: BIO
Certification: CE
Model Number: W7
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Packaging Details: Carton (240x235x100mm), 1.1Kgs/carton
Delivery Time: 7 Working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100 units / month
Contact Now
Detailed Product Description
Application: Cardiac, Abdomen Probe Element: 128
Depth: 90 / 130 / 160 / 190mm Applications: Cardiac, Abdomen
Measurement: B: Length,Area/Circumference,Angle,Trace,Distance B+M: Heart Rate, Time, LVIDd, LVIDs, SV, EF, Distance B+PW:Velocity, Heart Rate(2), S/D, Depth Working System: Apple IOS And Android, Windows
Frequency: 2.2/3.6Mhz Size Of Transducer: 25mm*16mm
High Light:

PDI wifi wireless portable ultrasound scanner

,

Cardiac wifi wireless portable ultrasound scanner

,

128 element home ultrasound scanner

128 Wireless Probe Type Ultrasound Scanner Wifi Wireless Portable Ultrasound Scanner For Cardiac



A phased array probe , used for echocardiography and with the capacity to utilise continuous wave doppler.



Full-body diagnostic imaging solution, designed for healthcare pros.



Simply flip the device, you can switch from shallow exams to deep exams. From the deep structures within the abdomen, superficial anatomy, the extremities and even to the heart.



Put it in your pocket and bring it to the bedside of every patient. Designed for more remotable and efficient diagnostic imaging.



With a high speed of 24 frames per second on your hand, you can get any small detail in maxium clarity for a quick diagnostic imaging. See patient's health issues in HD.



Get rid of extra wires and cables. It supports fully wireless operation makes it easy to disinfect in a very short time. Help to reduce the risk of infection during pandemic.



Specification





1 Scanning Mode Electronic phased array
2 Probe element 128
3 Frequency 2.2 / 3.6 MHz
4 Display mode B, B/M, Color, PW, PDI
5 Display mode B, B/M, Color, PW, PDI
6 Application Cardiac, Abdomen
7 Measurement

B: Length, Area / Circumference, Angle, Trace, Distance,

B+M: Heart rate, time, LVIDd, LVIDs, SV, EF, Distance

B+PW: Velocity, Heart Rate (2), S/D, Depth

8 Image frame rate 24/s
9 Cineplay 100/200/500/1000
10 Image save jpg, avi, mp4 and DICOM format
11 Wifi type 802.11g/20MHz/5G/450Mbps
12 Working system Apple IOS and Andriod, Windows
13 Language English, Russian, Italian, Spanish, Chinese, Portuguess (Brazil)
14 Battery Built-in 2800mAh Lithium Battery
15 Power consumption 4W (probe sun)/1.5W(probe stop)
16 Battery last 3 hours (working time) more than 5 hours (stand by time)
17 Battery charge by USB cable / wireless charge
18 Dinemsion 127*61*21mm
19 Weight 116g



Standard Configuration



1 Wireless ultrasound probe 1pc
2 USB A male to Type-C Female adaptor 1pc
3 Portable wireless charger 1pc
4 USB Cable for charging 1pc
5 Operation manual 1pc
6 Type-C cable 1pc



Optional



1 ipad Torlley 1pc





Advantages



1. Can be connected to IOS / Android / Windows devices by Wifi or Type-C cable.

​2. Smaller design, convenient for sterilization in the operating field.

3. Save more time and costs for doctors and patients.

​4. Built-in Wifi and lithium battery support wireless charging



Images



PDI WiFi Wireless Portable Ultrasound Scanner 128 Element 0



PDI WiFi Wireless Portable Ultrasound Scanner 128 Element 1
