3.6MHz Color Doppler Android Ultrasound Scanner 128 Element

Certification
China Wuxi Biomedical Technology Co., Ltd. certification
China Wuxi Biomedical Technology Co., Ltd. certification
Customer Reviews
Excelente localizador de veias, excelente serviço.

—— Adilson

ผลิตภัณฑ์ที่น่าทึ่ง มีประโยชน์มากสำหรับ MSK

—— Mrs. Wantanee

Yes. The image is very good!

—— Mr. Michael Oling

Good product!

—— Dr. WAN Chun Wai Macor

Good quality and delivery in time.

—— George

Professional service

—— Fekete

I'm Online Chat Now

3.6MHz Color Doppler Android Ultrasound Scanner 128 Element

3.6MHz Color Doppler Android Ultrasound Scanner 128 Element
3.6MHz Color Doppler Android Ultrasound Scanner 128 Element
3.6MHz Color Doppler Android Ultrasound Scanner 128 Element 3.6MHz Color Doppler Android Ultrasound Scanner 128 Element 3.6MHz Color Doppler Android Ultrasound Scanner 128 Element 3.6MHz Color Doppler Android Ultrasound Scanner 128 Element 3.6MHz Color Doppler Android Ultrasound Scanner 128 Element

Large Image :  3.6MHz Color Doppler Android Ultrasound Scanner 128 Element

Product Details:
Place of Origin: China
Brand Name: BIO
Certification: CE
Model Number: W7
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Packaging Details: Carton (240x235x100mm), 1.1Kgs/carton
Delivery Time: 7 Working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100 units / month

3.6MHz Color Doppler Android Ultrasound Scanner 128 Element

Description
Dimension: 127*61*21mm Weight: 116g
Display Mode: B, B/M, Color, PW, PDI Applications: Cardiac, Abdomen
Measurement: B: Length,Area/Circumference,Angle,Trace,Distance B+M: Heart Rate, Time, LVIDd, LVIDs, SV, EF, Distance B+PW:Velocity, Heart Rate(2), S/D, Depth Working System: Apple IOS And Android, Windows
Frequency: 2.2/3.6Mhz Size Of Transducer: 25mm*16mm
High Light:

3.6MHz android ultrasound scanner

,

Color Doppler android ultrasound scanner

,

128 element mini ultrasound scanner

2.2-3.6MHz Cardiac Color Doppler Probe Wifi Ultrasound Scanner Apple iOS and Android Windows Available



Specification



1 Scanning Mode Electronic phased array
2 Probe element 128
3 Frequency 2.2 / 3.6 MHz
4 Depth 90 / 130 / 160 / 190mm
5 Display mode B, B/M, Color, PW, PDI
6 Application Cardiac, Abdomen
7 Measurement

B: Length, Area / Circumference, Angle, Trace, Distance,

B+M: Heart rate, time, LVIDd, LVIDs, SV, EF, Distance

B+PW: Velocity, Heart Rate (2), S/D, Depth

8 Image frame rate 24/s
9 Cineplay 100/200/500/1000
10 Image save jpg, avi, mp4 and DICOM format
11 Wifi type 802.11g/20MHz/5G/450Mbps
12 Working system Apple IOS and Andriod, Windows
13 Language English, Russian, Italian, Spanish, Chinese, Portuguess (Brazil)
14 Battery Built-in 2800mAh Lithium Battery
15 Power consumption 4W (probe sun)/1.5W(probe stop)
16 Battery last 3 hours (working time) more than 5 hours (stand by time)
17 Battery charge by USB cable / wireless charge
18 Dinemsion 127*61*21mm
19 Weight 116g



Standard Configuration



1 Wireless ultrasound probe 1pc
2 USB A male to Type-C Female adaptor 1pc
3 Portable wireless charger 1pc
4 USB Cable for charging 1pc
5 Operation manual 1pc
6 Type-C cable 1pc



Optional



1 ipad Torlley 1pc



Images



3.6MHz Color Doppler Android Ultrasound Scanner 128 Element 0



3.6MHz Color Doppler Android Ultrasound Scanner 128 Element 1



A phased array probe , used for echocardiography and with the capacity to utilise continuous wave doppler.



Advantages



1. Can be connected to IOS / Android / Windows devices by Wifi or Type-C cable.

​2. Smaller design, convenient for sterilization in the operating field.

3. Save more time and costs for doctors and patients.

​4. Built-in Wifi and lithium battery support wireless charging
