Product Details:
|
| Image Specifications: | 1280*720 BMP | Battery Capacity: | 1600mAh |
|---|---|---|---|
| Working Hours: | 3.5 Hours | Weight: | 96.27g |
| Size: | 38*32*160.5mm | UV Light Wavelength: | 395nm |
| Highlight: | digital skin moisture meter,skin analyser digital |
||
Skin Moisture Sensor Digital Skin Analyzer with Skin Lense and Scalp Lense for 4 Hours Continuous Working
Brief Introduction
This skin analyzer is helpful for doctor (beauticians and health-care workers) to abserve, record and store images of
skin and scalp.
With 50 times skin lense, It can analysis the oil, water, pigment and flexible for the skin, showing the percfentage
compared to standard reference.
With 200 times scalp lense, It also can give the pictures of all kinds possible scalp conditions
(like dry, sensitive or dandruff and so on) to compare yours.
Operation steps
This smart digital skin analysis machine can be connected to PC, iPad and mobilephone via WiFi.
Operation is easy as follows,
|
1. Scan the QR code to download APP to your mobilephone.
2. Turn on the skin analyzer.
3. Connect the WIFI named "mlg_p1XXXXXX",the password is “88888888”
4. Back to the desktop,click APP “easylnsmile” and then enter system.
5. Click on “Config” to choose skin or scalp
6. After setting ,please click “Save” ,then back to system top ,press “enter”
7. Clean the analyzer lens and stick on the skin,the image is the best then you can capture (Note: before the image shooting ,please keep the lens state of your skin)
8. Select a best picture you took,click the analysis and then it will enter the test interface . Click oil,water,pigment and flexible --the test result is in left ,the right data is a healthy skin.
9. Select different angle of skin image to contrast,choose the image and then press “compare”, a maximum of 9 images one time.
10. It can switchable analyzer's lens to check the the underside of the skin or switches to a UV lens to see the large pore and hari follicle.
|
Feature of Skin Analysis Device
|
1. Wi-Fi function ,transmit image to smart system -mobile phone ,tablet pc and computer
2. 1/4 CMOS 2.0 mega pixel high resolution lens,auto-focus.
3. Two metal probe test the moisture ans sebum
4. Thress mode: skin epidermis ,skin dermis and UV
5. Build-in lithium battery ,once full charged can use more than 5 hours
6. Suit for IOS system,Android system and Micro window system
7. Free APP , that can analysis the moisture of the skin ,oil content ,elasticty ,pigment
8. Cam make recording via software .
9. Optional 50 times lens(for skin) and 200 times lens (for scalp )
|
Specifications of Skin Moisture Sensor
|
1. Battery capacity:1600mAh
2. Battery voltage:3.7-4.2V
3. Working hours:3.5 hours
4. Charging time:3 hours
5. Power:2W
6. Charging voltage:5V
7. Charging current:600mA
8. Transmission data format:720P/25fps
9. Image Specifications:1280*720 BMP
10. Weight (net weight per unit):96.27g
11. Size:38*32*160.5mm
12. White light color temperature:10000K
13. UV light wavelength:395nm
14. SENSOR photosensitive area:1/3“
15. SENSOR resolution:1280*960
|
Our images
