Product Details:
Place of Origin: China
Brand Name: BIO
Certification: CE
Model Number: HSL-NEW
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Packaging Details: Carton (36*29*26cm) 3kgs
Delivery Time: 7 working - days since getting full payment
Payment Terms: Credit card, Paypal, T/T
Supply Ability: 100 units / month
Contact Now
Detailed Product Description
Image Resolution: 16MP Screen: 3.97 Inch TFT-LCD Color Touch Screen
Storage: 16GB MicroSD Card Product Name: Digital Handheld Slit Lamp
Magnification: 10X Working Distance: 80mm
Slit Width: 0mm~12mm Continuously Adjustable Object Eyepiece: 0.42X
Aperture Diameter: 0.2mm,1mm, 5mm, 12mm Light Source: White LED
Transmission: Mini USB,WIFI,BT Imaging /Video Format: JEPG/3GP
High Light:

portable ophthalmic equipment

,

non mydryatic ophthalmic equipment

,

digital ophthalmic equipment

Digital Non-mydryatic Portable Fundus Camera Handheld Ophthalmoscope With 3.97 Inch Touch Screen



Product Introduction



Handheld Slit Lamp.HSL-NEW,a portable medical camera for anterior segment imaging, diagnosis and especially for anterior disease screening. It's compact, easy to obtain high definition images. It can be conveniently applied to rapid screening, out diagnosis, bedside diagnosis and remote medical treatment,etc.





Product Advantage



1. Real-time image display, 10 times magnification

2. Brand new optical system, larger field of view

3. Video function offering live data

4. Easy to operate and high definition imaging

5. Multi data transfer and storage system

6. Light weight 850g, movable and portable

7. Battery works for 6 hours continuously



Product Features



High definition imaging 1)Real-time focus system
2)Real-time dynamic display
New optical system 1) a wide field of vision
2) For anterior segment photography
3) Professional optical design
Easy to operate and capture high definition images 1) Ergonomic application, ergonomic design
2) One-click to capture images
Multi data transfer and storage system 1) Built-in 16G storage(can storage 80,000 images)
2) USB connect the computer and export.
3) Real-time Wifi, computer, mobile terminal and cloud transmission, as well as data analysis and software upgrading services.
Lightweight and portable 1) 850g
2) Remote diagnosis and mobile medical preferred
3) Battery works continuously:6 hours



Product Specification



Model HSL-NEW
Product name Digital handheld slit lamp
Screen 3.97 inch TFT-LCD color touch screen
Illumination angle ≥30°
Magnification 10X
Working distance 80mm
Slit width 0mm~12mm continuously adjustable
Object eyepiece 0.42X
Aperture diameter 0.2mm,1mm, 5mm, 12mm
Filter Heat-absorption, Red-free, Cobalt blue
Light source White LED
Image resolution 16MP
Imaging /Video format JEPG/3GP
Transmission Mini USB,WIFI,BT
Storage 16GB MicroSD card
Power 3.6V/3400mAh rechargeable battery
Forehead rest bar ≥10mm
Numerical aperture 0.05
Interface Micro USB
Focus Mode Auto
N. Weight 850g(Typical)
Size 14*12*23cm
Packing size 36*29*26cm



Digital Non Mydryatic Portable Ophthalmic Equipment 0Digital Non Mydryatic Portable Ophthalmic Equipment 1Digital Non Mydryatic Portable Ophthalmic Equipment 2





BIO-catalogue for Digital Hand-held Slit Lamp.pdf
