Product Details:
|
| Image Resolution: | 16MP | Screen: | 3.97 Inch TFT-LCD Color Touch Screen |
|---|---|---|---|
| Storage: | 16GB MicroSD Card | Magnification: | 10 Times |
| Working Distance: | 80mm | Slit Width: | 0mm~12mm Continuously Adjustable |
| Aperture Diameter: | 0.2mm,1mm, 5mm, 12mm | Filter: | Heat-absorption,Grey,Red-free,Cobalt Blue |
| Light Source: | White LED | Power Supply: | 3.6V/3400mAh Rechargeable Battery |
| Interface: | Mini USB | Object Eyepiece: | 0.42X |
| Transmission: | Mini USB,WIFI,BT | Product Name: | Digital Handheld Slit Lamp |
| Highlight: | WIFI Digital Fundus Camera,Telemedicine Application Digital Fundus Camera,0.2mm Digital Fundus Camera |
||
High Efficient Handheld Ophthalmology Slit Lamp Ophthalscope With WIFI Function Telemedicine Application
HSL-NEW, Digital Hand-held Slit Lamp is used for anterior segment imaging,diagnosis,especially for anterior disease screening. Combining observation with imaging, it offers clearer observation and higher definition images of eyelid,conjunctiva, cornea, iris, lens and vitreous,etc. With quick lens adjustment and lightbody, it is much easier and more convenient to be applied in rapid screening, out diagnosis, clinical observation and remote medical treatment.
Packing List
1. Digital handheld slit lamp 1 pcs
2. Forehead rest 1 pcs
3. USB cable 1 pcs
4. Power adapter 1 pcs
5. Battery 18650 1 pcs
6. User's manual 1 pcs
The device is consists of forehead module,lens module,illumination module,base module ,camera module,battery,shell,USB cable and software disc.
Product Advantage
1. Easy to capture high resolution and stable images of anterior segment
2. Easy to operate and carry out for outdoor diagnosis
3. Auto focus and real-time focus
4. Real-time display for observing
5. WIFI,BT connection to storage and transmission
6. Automatic ID identification
7. Ultra-light portable, remote diagnosis and mobile medical preferred
Product Feature
1. High definition imaging
1)Real-time focus system
2)Real-time dynamic display
2. New optical system
1) a wide field of vision
2) For anterior segment photography
3) Professional optical design
3. Easy to operate and capture high definition images
1) Ergonomic application, ergonomic design
2) One-click to capture images
4. Multi data transfer and storage system
1) Built-in 16G storage(can storage 80,000 images)
2) USB connect the computer and export.
3) Real-time Wifi, computer, mobile terminal and cloud transmission, as well as data analysis and software upgrading services.
5. Lightweight and portable
1) 850g
2) Remote diagnosis and mobile medical preferred
3) Battery works continuously:6 hours
Product Specification
| Model | HSL-NEW |
| Product name | Digital handheld slit lamp |
| Screen | 3.97 inch TFT-LCD color touch screen |
| Illumination angle | ≥30° |
| Magnification | 10X |
| Working distance | 80mm |
| Slit width | 0mm~12mm continuously adjustable |
| Object eyepiece | 0.42X |
| Aperture diameter | 0.2mm,1mm, 5mm, 12mm |
| Filter | Heat-absorption, Red-free, Cobalt blue |
| Light source | White LED |
| Image resolution | 16MP |
| Imaging /Video format | JEPG/3GP |
| Transmission | Mini USB,WIFI,BT |
| Storage | 16GB MicroSD card |
| Power | 3.6V/3400mAh rechargeable battery |
| Forehead rest bar | ≥10mm |
| Numerical aperture | 0.05 |
| Interface | Micro USB |
| Focus Mode | Auto |
| N. Weight | 850g(Typical) |
| Size | 14*12*23cm |
| Packing size | 36*29*26cm |
