Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer

Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer
Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer

Large Image :  Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer

Product Details:
Place of Origin: China
Brand Name: BIO
Certification: CE
Model Number: BS6000
Display mode: Projecting to human skin
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Packaging Details: 1 unit / carton (43.5*33*12.5cm) 3kgs
Delivery Time: 7 working - days since getting full payment
Payment Terms: Credit card, Paypal, T/T
Supply Ability: 100 units/month

Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer

Description
Image Model: 8 Inch Touch Screen Wavelength: 850nm
Imaging Technology: 2 Million Pixels Infrared Camera Imaging Depth: ≤10mm
Resolution: 800*1280 Best Imaging Distance: 140-180mm
High Light:

portable vein finder

,

vein locating device

Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer



Technical Parameters



Item Parameter
Image model 8 inch touch screen
wavelength 850nm
imaging technology 2 million pixels infrared camera
imaging speed >32 frame/second
imaging depth ≤10mm
resolution 800*1280
registration accuracy <0.2mm
best imaging distance 140-180mm
infrared light energy 0.36w



Application people



Infants

Children

Obese patients

Patients with edema

Patients with tumor and chemotherapy

Patients with venous blood vessels



Working principle



The infrared light as kind of invisible light widely exists in nature;Such as sunlight,heater etc..

Hemoglobin in the blood absorbing infrared light is different from other organizations;

Using certain wavelength of infrared radition to the skin,hemoglobin in subcutaneous

blood vessels will absorb more infrared light,and other organizations of absorption are less,

so that we can distinguish the blood vessels and other organizations in infrared images.

Infrared image is taken by infrared camera,after optimization and highlightling the

color&shape by professional image processing software, then output the pictures

on the screen,or projection methods,we can clearly see the subcutaneous vascular distibution.

location.direction.etc.



Product Advantages

  1. Large 8inch screen,high-resolution display,more clear image
  2. Professional medical image processing system
  3. Screen display more suitable for human visual habits,no glare and fatigue
  4. Real and reliable image,visual effect more close to naked eye
  5. Needle clearly visible during puncture,easy to operation
  6. No artifacts interference by hair,wrinkles,embossment etc
  7. Delicate and portable,equipped with specified support,suitable for any occasion

Images for Medical Vein Viewer



Upgraded Non - Contact Version 850nm Infrared Vein Finder For Veinpuncture




Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer 1



Resolution of 800*1280 Near Infrared Projectiion Vein Finder Portable Medical Vein Viewer 2

catalogue for vein finder BIO_BS6000.pdf
